Scissor All Terrain Athena 870 Bi Leveling on Tracks
The Athena 870All Terrain Scissor Lift can replace the need for multiple machines on site by performing the work of a slab scissor and a rough terrain elevated work platform all in one unit.
- Min. width: 1,30 m
- Capacity: 250 kg
- Max height: 7,90 m
Tow Vehicle needs have a 3.5T tow capacity.
Hire Rates (including GST)
| Half Day | $220 |
|---|---|
| Day | $300 |
| Weekend (8 hours) | $300 |
| Week (5 Days) | $1250 |
Scissor All Terrain Athena 870 Bi Leveling on Tracks
| Platform capacity | 250 kg (2 op.) |
| Platform size | 1.50 x 1.20 m |
| Max working height | 7.9 m |
| Max height platform floor | 5.9 m |
| Moving height | 6.0 m (5.0 m) |
| Powered | Honda iGX 390 |
| Powered | Lithium Power Pack 100Ah-48V |
| Powered (option) | Diesel Hatz 1B40 |
| Accelerator | Automatic |
| Undercarriage | Bi-Levelling |
| Platform levelling | Automatic |
| Longitudinal levelling Front | +/- 16° |
| Longitudinal levelling Rear | +/- 20° |
| Lateral levelling | +/- 15° |
| Electric pump (option) | – |
| Hydraulic commands | Proportionals |
| Direction-Control System | Yes |
| Easy-Drive System | Yes |
| Kit for high speed | max 2.20 km/h |
| Ground emergency | Yes |
| Control of inclination | Automatic |
| Pro-active Levelling | – |
| Gradeability | 25° |
| Side slope | 21° |
| Length | 2,03 m |
| Width | 1.30 ÷ 1.50 m |
| Minimum machine height with folded railings and narrow tracks | 2.28 (1,98) m |
| Minimum machine height with folded railings and wide tracks | 1.98 (1,68) m |
| Total weight | 2460 kg |
| Compliance | EN 280, ANSI, CSA, ASNZS1418 |
